k4 series

Think big. Or, if you prefer, bigger. The k4 is a roomy 11' x 17' or 13’ x 17’ with an optional interior full bath and kitchenette. Starts at $65k


From 191 to 226 square feet.

k4 series

+ k4.10 basic (11’x17’) starting at $67.5k

+ k4.10 w/bath (11’x17’) starting at $77.5k

+ k4.10 w/bath & kitchenette (11’x17’) starting at $92.5k

+ k4.12 (13’x17’) starting at $77.5k

+ k4.12 w/bath (13’x17’) starting at $87.5k

+ k4.12 w/bath & kitchenette (13’x17’) ADU starting at $102.5k

financing available through Acorn Finance

k4.10

k4.10
k4.12

k4.12

  • Framing — M.H.S.** structural anodized aluminum framing with proprietary locking system. Available in silver or bronze anodized.

    Exterior — Corrugated galvalume or smooth, natural cement board with corrugated roofing. Hardwood siding or other corten corrugated siding and roofing also available with up charge.

    Insulation — SIP panels (Structural Insulated Panels) in floors, roofs and ceilings

    Glazing — Highest quality dual-glazed low-e glass. Includes screens and locks. Frames are available in clear or bronze/black anodized finish.

    Interior Walls — White shiplap horizontal siding or finished/unfinished birch plywood with aluminum dividers.

    Ceiling/Undercarriage — White laminate.

    Floor — Maple hardwood. Hardwood tongue and groove flooring available at an additional cost.

    Bathroom — Frosted sliding glass door, high density waterproof cement board on all interior surfaces including shower stall, floors and walls. White powder coated aluminum shower pan. Ikea or similar fixtures.

    Electrical — Dimmable, recessed LED ceiling lights, bathroom wall mount and exterior on some modules. Prewired and switched as per electrical plans. IKEA or similar quality fixtures including sink with vanity, lighting, toilet and shower.

    Kitchenette (k4 series) — Under-counter fridge, 4’ counter top, two-burner cooktop, shelving, microwave, Ikea or similar fixtures.

    Kitchen (k5 series and up) — Two-burner cooktop, 8’ counter top, full size refrigerator with freezer, shelving, microwave, pantry, Ikea or similar fixtures.

    + View Gallery

  • 12’ Side canopy — $2,200

    17’ Front canopy — $2,700

    10’ Hardwood deck with kitHAUS aluminum framing — $5,200

    12' Hardwood deck with kitHAUS aluminum framing — $6,200

    16' Hardwood deck with kitHAUS aluminum framing — $8,200

    Hardwood 4x8' vertical louver panels — $1,500 per panel

    Alternative material louver sliding panels — please inquire

    Plywood finished ceiling — please inquire

    Hardwood T&G flooring — please inquire

    Corten corrugated metal cladding — please inquire

    10' Ceiling with taller glass doors — please inquire

    Alternate decking material available — please inquire

    Bronze/black anodizing — please inquire

    Hardwood exterior cladding — please inquire

    Custom cladding — please inquire

    HVAC mini-split systems — please inquire

    Ceiling fan — please inquire

    Bathroom radiant floor heating — please inquire

    Window shade option — please inquire

    Mesh pest barrier — please inquire

    Double door slider — please inquire

    + View Gallery

Notes

Typical installation by kitHAUS team approximately 15% on non-permitted projects and 20%-24% on permitted projects of module price.

Delivery charge TBD based on location.

*Check with your local municipalities for permit exemptions
**US Systems / Modular Housing System
***Site conditions will vary depending on permitted or non-permitted project.
